MiniPods
applied acoustics’ MiniPod range delivers precise positioning using global navigation satellite systems (GNSS), whilst operating in the challenging environment of the transition zone.
Read More- Robust GNSS receivers with integrated L1 + L2 + L5 antenna
- Wide band corrections or external RTCM
- Internal and external shock mounts
- Atlas correction options
- Worldwide RF remote wireless data options
- Marinestar L-Band correction service
- RTK Moving Base and Rover Operation
- Assembly shock rated to 75G for field endurance
in harsh conditions
- Seismic source positioning
- Seismic streamer head and tail positioning
- Surface positioning of towed sensors in shallow water
- Surface positioning of ROVs, AUVs, USVs
- Subsea excavation vehicles
- Vehicle recovery operations
- Asset relocation
- Remote asset monitoring
First-class performance at all depths
The compact 101G MiniPod is ideal for smaller platforms where size, weight and limited mounting options are critical factors. Depth rated to 50m, it can be safely installed close to the water surface and transmit its position to a mother vessel over a range of up to 2km. The 103G MiniPod and 106G MiniPod models are depth rated to 1000m and 6000m respectively, making them the perfect partner for deep-water work class ROVs and AUVs.
The 200 Series MiniPod range features lightweight and rugged Tri-band GNSS receivers that offer various configuration options. These receivers can be utilized in RTK base, RTK rover, and RTK moving base solutions, allowing multiple MiniPods to operate simultaneously. Additionally, external sensor data can be integrated into the wireless protocol.
The 200 series is shock-rated for assembly to withstand up to 75G, ensuring durability in harsh conditions such as rock cutting and cable trenching.
